Product series | GZ130PEC01 | GZ130PEC02 | |
Features | COF packaging color | COB package color | |
Resolution | 3552×3840 | ||
Pixel size | 6.3μm×6.3μm | ||
Display size | 1.3” （22.38mm×24.19mm） | ||
Pixel arrangement | RGB hexagon | ||
Brightness uniformity | ≥ 90% | ||
Contrast | 100000:1 | ||
Grayscale | Level 256 | ||
Refresh rate | 30Hz~90Hz | ||
Video interface | 4-lane/2port MIPI，DSI-2 1.0 D-PHY v1.1 DCS 1.3 3-lane/2port MIPI，DSI-2 1.0 C-PHY v1.1 DCS 1.3 | ||
Maximum brightness | 5000nit | 5000nit | |
Power consumption@5000nit | 1.5W | 1.5W | |
Supply voltage | VAN | +3.3V | |
VDD | +1.8V | ||
VEE | -5V | ||
Operating temperature | -20℃~+65℃ | ||
