| Parameter | Value | |
Optical Characteristics | Field of view (FOV) | 30° |
| Resolution | 1280x720 | |
| Micro-display | 0.30”Si-OLED | |
| Color | RGB | |
| Maximum luminance | ≥1000 nits | |
| Eye-box | 9x6 mm2 | |
| Eye-relief | 15 mm | |
| Contrast Ratio | ≥10000:1 | |
| Transmittance | ≥80% | |
| Brightness Uniformity | ≥60% | |
| Distortion | ≤1% | |
Electrical Characteristics | Input Video Signal Format | Single-lane MIPI |
| Power Consumption @ Max Brightness | 160mW | |
| Refresh Rate | 30Hz~120HZ | |
| Others | Total weight | ≤13.4 g |
| Operating Temperature | -10℃~+40℃ | |
| Storage Temperature | -20℃~+30℃ |
